GENERALCapacity650VADimension (mm)286 x 96 x 138 (D x W x H)Weight (kg)4.3INPUTVoltage Range162 ~ 290VAC (Single boost) 140 ~ 300VAC (Double boost)Frequency50Hz/60Hz (Auto-sensing)PhaseSingle GNDOUTPUTVoltage Range220-240VACBattery Mode220-240VACFrequency50Hz ±1% (Battery mode)WaveformSimulated sine wave (Battery mode) Sine wave (AC mode)Transfer Time2ms typicalBATTERYType12V/8.2AH x 1Backup Time8 – 20 mins depending on loadRecharge Time2-4 hours recover to 90% capacityINTERFACE & INDICATORSInterfaceRS232, USB port, RJ45/RJ11 (Optional)DisplayLED/LCD OptionalAlarmBatt. Mode, low battery, overload, fault, etc.PROTECTION/MONITORINGShort Circuit ProtectionYes (Line mode & battery mode)Surge ProtectionYesAlarmAudible & VisualOverload ProtectionLine mode : 100 – 120% 1 min change to fault mode >120% change to fault mode immediatelyBattery mode : 100 – 120% 1 min change to fault mode >120% change to fault mode immediatelyIntelligent BatteryPrevent overcharging of batteryManagementProtect battery and prolong battery lifeReal Panel1. AC Mode Indicator Green LED Lighting 2. Battery Mode Indicator Battery Normal : Yellow LED Lighting and Blinking every 30s Battery Low : Yellow LED Lighting and Blinking every 2s 3. Overload and Fault Indicator Overload : Red LED Blinking every 2s Fault : Red LED Lighting 4. Power Switch 5. Power AC Input 6. Backup Outlets
